General |
ATEX Classification |
Group II Category 2 GD |
Application |
Zone 1 and 21 areas to EN 60079-10-1 and EN 60079-10-2 |
Certificate |
- EU Type Examination Certificate: CML18ATEX3358X
- IECEx Certificate of Conformity: IECEx CML 18.0167X
|
Coding |
Ex db eb mb op is IIC T4 Gb, Ex mb op is tb IIIC T85°C Db IP6X. |
Enclosure |
Marine grade aluminium body with polycarbonate diffuser. Driver enclosure with epoxy powder finish (RAL 9005) |
Geartray |
Aluminium |
Entry |
4 x M20 cable entries - 2 at each end [3 cable entries on Emergency with battery stick] |
Termination |
3 core 4mm² max conductor [4 core on Emergency] with looping one end and 16A rating through wiring |
Installation |
2 x M8 mounting points located on the rear of the body |
Control Gear |
Electronic Driver |
Colour Temperature (CCT) |
5000K (Cool White) |
Colour Rendering Index (Ra) |
>70 |
Maintenance) |
Front access panel with Torx screws |
LED Lifetime @ 60°C Ambient |
L70 > 200,000hrs |
Maintenance Free Lifetime @ Ambient |
120,000hrs @ 25°C; 90,000hrs @ 60°C |
Battery |
Swappable Ni-MH (6V) battery stick [Emergency version only] |
Emergency Duration |
90 mins (25% output) |
Ingress Protection |
IP66/67 to EN 60529 |
Surge Protection |
4kV |
Electrical Supply |
- 110-277V AC, 50/60Hz
- 127-250V DC
|
